Q45ULIU64BCRQ

Marka : Banner

Ürün Kodu: : 47557

Range: 250 mm - 3 m

Input: 15-24 V dc

Output: Selectable 0-10 V dc or 4-20 mA sourcing

Cable: Mini-Style Integral QD

-
+

Power
DC
PFM Output
No
Sensing Beam
Ultrasonic
Jam Detection
No
PC Configurable
No
IP Rating
IP67
NEMA / UL Type Rating
NEMA 4X
Supply Voltage
15-24 V dc
Pin / Wire Count
5
Item Status
RELEASED
Sensing Mode (General)
Proximity
Sensing Mode (Detailed)
Time of Flight
Housing Style
Rectangular
Device Type
Sensor
Primary Housing Material
PBT
Input/Output
Analog
Analog Output Configuration
0-10 V dc or 4-20 mA
Connection
Integral QD
Quick Disconnect Type
7/8 in. (Mini)
Max Sensing Distance (mm)
3000
Minimum Sensing Distance (mm)
250
Adjustments
Teach Button; DIP Switches
Number of Pins
5
Max Operating Temperature (C)
70
Min Operating Temperature (C)
-25
Minimum Response Time (ms)
80
Ultrasonic Frequency (kHz)
128
Laser Control
No
Feature: Remote Teach
Yes
Feature: Washdown Rated
No
Feature: Clear Object Detection
Yes
Feature: Timing (Hold/Delay)
No
Feature: Chemical Resistant
No
Feature: Pump-in/ Pump-out
No
Feature: Quick Disconnect
Yes
Feature: Health/Marginal Signal Output
No
Application: Ultrasonic
Yes
Common Ethernet Protocol
No
RS-232
No
Wireless
No
EPLAN Status
Published
EPLAN Original Sent Date
06/20/2022
