QT50ULBQ6

Marka : Banner

Ürün Kodu: : 02728

Range: 200 mm - 8 m

Input: 10-30 V dc

Output: Analog: 0-10 V or 4-20 mA

Cable: 5-pin M12 Integral QD

-
+

Power
DC
PFM Output
No
Sensing Beam
Ultrasonic
Jam Detection
No
PC Configurable
No
IP Rating
IP67
NEMA / UL Type Rating
NEMA 4X
Supply Voltage
10-30 V dc
Item Status
RELEASED
Sensing Mode (General)
Proximity
Sensing Mode (Detailed)
Time of Flight
Housing Style
Rectangular
Device Type
Sensor
Primary Housing Material
PBT
Input/Output
Analog
Analog Output Configuration
0-10 V dc or 4-20 mA
Connection
Integral QD
Quick Disconnect Type
M12
Max Sensing Distance (mm)
8000
Minimum Sensing Distance (mm)
200
Number of Pins
5
Ultrasonic Frequency (kHz)
75
Laser Control
No
Feature: Remote Teach
Yes
Feature: Washdown Rated
No
Feature: Clear Object Detection
Yes
Feature: Timing (Hold/Delay)
No
Feature: Chemical Resistant
No
Feature: Pump-in/ Pump-out
No
Feature: Quick Disconnect
Yes
Feature: Health/Marginal Signal Output
No
RS-232
No
EPLAN Status
Published
